Aviation Plug Temperature Humidity Sensor Probe for Industrial High Precision Calibration
Product Details:
| Place of Origin: | Anhui, China |
| Brand Name: | ZHICE-ELEC |
| Model Number: | HT85-S |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 piece |
|---|---|
| Price: | $150.00/meters 5-9 meters |
| Packaging Details: | Bubble wrape & Carton Packing |
| Supply Ability: | 50 Meter/Meters per Month |
|
Detail Information |
|||
| Warranty: | 1 Year | Customized Support: | OEM |
|---|---|---|---|
| Product Name: | Standard Temperature & Humdity Probe | Application: | Temperature Testing & Reference |
| Temperature Range: | -40-125℃ | Humidity Range: | 0-100%RH |
| Calibration Certificate: | Can Provided | Color: | Dark Grey |
Product Description
HT85-S Standard temperature and humidity sensor can be used to measure relative humidity and temperature with excellent accuracy, repeatability and long-term stability. It can be used in HVAC, food, building equipment, paper, textile, medicine, electronics, equipment and other industries.
ZHICE-ELEC is committed to the research and development and production of high-precision temperature measurement sensors, which are widely used in aerospace, petroleum and petrochemicals, universities, laboratories, metrology institutes, new energy, automobile manufacturing, biomedical, intelligent buildings and other industries. ZHICE have compelete production line from parts assembly to sensor calibration, and we aims to provide high precision, high durability temperature products.
Product Name | Standard temperature and humidity sensor |
Model | HT85-S |
Range | -40-125℃ 0-100%RH |
Accuracy | ±0.2℃ (20-50℃) ±2.0%RH @25℃ (10-100%RH) |
Repeatability | 0.15%RH |
Hysteresis | ±0.8%RH @25℃ |
Response time | temperature: 2s humidity: 4s |
Long term drift | temperature: ≤0.03℃/yr shumidity: ≤0.2%RH/yr |
Signal output | 0-1VDC = 0-100%RH 0-1VDC =-40-60℃ |
Power | 4.5-5.5VDC |
Power consumption | 3.5mA@5V |
Cable length | MAX 10m |
Probe material | polycarbonate |
Size | Φ24*146mm |
Protection level | IP30 |
